Shift Line Menu

Everest M

Reverb-Delay

As any mountain climber would tell you, reaching one peak will always make you crave for another. Here at Shift Line, we are ascending our next slope: the A+ Everest M.
The Everest M is a new revision of the Everest reverb/delay pedal. It retains the gorgeous sounds and simple controls of the original, adding new features for greatly improved functionality.

Stereo version available

Key Features:

Sound:

6 reverb and delay algorithms

Infinity Mode (infinite sustain)

Delay and reverb run in parallel. Either effect can be added to the mix at a desired level or turned off

Fully analog dry signal path

Switchable reverb tails in bypass

Kill Dry (the option to completely remove the dry signal from the mix)

Controls:

The REVERB knob controls reverb volume. Turn this knob fully CCW to disengage the reverb

The MIX knob controls the volume of the wet signal

The REGEN knob simultaneously controls delay feedback and reverb decay

The TIME knob controls delay time and affects reverb decay for effect sync. Turn this knob fully CCW to disengage the delay

The MODE switch selects one of the six reverb/delay algorithms

The BYPASS switch is multifunctional:
- Press once to turn the effect on/off
- Press and hold to go into the infinite sustain mode (Infinity Mode)
- Press and hold while selecting an algorithm to access Bank

List of Algorithms

Some sounds were exclusively created for the Everest M, while others were ported from the original and improved upon.

The algorithms are split into two banks; each bank contains three sounds. Bank 1 holds extended versions of the original Everest algorithms with access to Infinity Mode. Bank 2 contains new sounds.
Flick the MODE switch to select an algorithm from Bank 1. Press and hold the bypass switch while flicking the MODE switch to access the sounds from Bank 2.

Bank 1 (Blue LED)
Selectable by the MODE switch:
- Up: Moonshine
  The initial delay repeats and reverb reflections are accompanied by octave sounds for a weird, otherworldly effect
- Center: Eclipse
  Modulated delay repeats and solemn reverb reflections make for a perfect soundscape of the Himalayas at dusk
- Down: Sunshine
  A sunny, snowy and frosty morning right atop the Everest. The delay and reverb in this mode are so bright and cold they will send shivers down your spine!
Bank 2 (Red LED)
Selectable by the MODE switch while the BYPASS footswitch is held down:
- Up: Low
  A loud lower octave with a long decay is mixed into the reverb reflections. Together with filtered delay repeats, this creates a powerful low-frequency pad
- Center: Tape
  Modulated tape-style delay with characteristic repeat degradation is accompanied by dark vintage reverb
- Down: Digital
  Clean delay repeats with no audible degradation (like the ones in vintage digital delay machines) coupled with bright reverb reflections make for a very "transparent" mode
Infinity Mode (Infinite Sustain)
Press and hold the bypass switch for more than 0.3 seconds to enter Infinity Mode which simulates turning the REGEN knob to the max. In this mode, reverbs become infinite or very long (2–5 minutes), delays go into maximum feedback, and the LED starts flashing in two colors. Release the bypass switch to let REGEN go back to the setting of the knob.

Video Gallery

Bypass and Indication

The Everest M utilizes active bypass. The dry signal is unaffected. Due to the active bypass, there is no audible clicking, and two independent global modes are available:
1. Tails: Only the input is engaged when the bypass switch is pressed. This way, reverb tails keep playing after the effect has been turned off
2. Kill Dry: The dry signal is completely removed from the mix
Selecting the Bypass Mode:
1. Set the MODE switch to the position corresponding to the global bypass mode you wish to turn on or off:
  • Up: Tails
  • Down: Kill Dry
2. Press and hold the BYPASS footswitch
3. Unplug the power supply cable from the pedal, then plug it back in
4. The LED will light up in violet. When it turns off or starts flashing, release the BYPASS footswitch
5. The global mode status has been changed (e.g. if the tails mode was previously disengaged, it has now been turned on, and vice versa)
Indication on Power-Up
When the pedal is powered up, the LED color indicates the global mode(s) that are currently engaged:
- No indication: classic mode (Tails OFF, Kill Dry OFF)
- Blue: Tails ON, Kill Dry OFF
- Red: Tails OFF, Kill Dry ON
- Violet: both Tails and Kill Dry are ON
Indication on Power-Up
When the pedal is powered up, one of the LEDs lights up to indicate the currently selected bypass mode:
- Left LED: Tails
- Lower LED: No tails, no input monitoring
- Right LED: Continuous input monitoring
Indication in Use
When the pedal is turned on, the LEDs indicate which sound bank is currently active:
- All three LEDs light up: an algorithm from Bank 1 is selected
- Only the lower LED lights up: an algorithm from Bank 2 is selected
- LEDs are flashing and spinning around: Infinity Mode is engaged

Notes:

Max delay time is 0.85 seconds

The pedal's current draw may reach 80mA, so battery life is unlikely to exceed 1 or 2 hours. For regular use, it is strongly recommended to use a matching PSU

Algorithms in banks 1 and 2 are coupled by their general character: bright / dark / octave

Specifications:
